| Technical Data | Scrubbing Width | Squeegee Width | No. of Brushes | Max. Productivity | Solution Tank Capacity | Recovery Tank Capacity | Main Supply | Brush Diameter | Maximum Speed | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| MODEL | mm | mm | - | Sq. mtr/Hr | Ltrs | Ltrs | Volts/Ah | mm | Km/Hr | Kg |
| KV-180 | 960 | 1200 | 2 | 8640 | 265 | 280 | 24 / 240 | 480 x 2 | 0 to 9 | 435 |
| KV-270 | 1060 | 1380 | 2 | 9540 | 250 | 270 | 36 / 240 | 530 x 2 | 0 to 9 | 583 |
| Technical Data | Traction motor Watts | Brush motor Watts | Vacuum motor Watts | Brush pressure MPa | Brush speed rpm | Grade ability % | No. of Batteries | Working Hours | Noise level dBA | Dimensions (LxWxH) cm |
|---|---|---|---|---|---|---|---|---|---|---|
| KV-180 | 800 | 550 x 2 | 554 | 4.5 | 180 | 25 | 4 x 6V | 3 to 5 | 67 | 163 x 87 x 140 |
| KV-270 | 850 | 650 x 2 | 800 | 4.5 | 180 | 25 | 6 x 6V | 4 to 6 | 65 | 187 x 108 x 146 |
